Factory special motor overload protection helical zero differential protection filter worm screen centrifuge

1.0 Sets
MOQ
Factory special motor overload protection helical zero differential protection filter worm screen centrifuge
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
Type: Centrifuge
Product Type: Worm centrifuge
Condition: New
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: New Product 2020
Warranty of core components: 1 Year
Core Components: Bearing, Gearbox, Motor
Voltage: 220v/240v
Power: 3kw
Weight: 450kg
Dimension(L*W*H): 1120*1050*800mm
Warranty: 1 Year
Key Selling Points: Easy to Operate
Applicable Industries: Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Printing Shops
Showroom Location: None
Model: LWL/Y200
Drum diameter: 200mm
Drum length: 176mm
Speed: 4000rpm
Separation factor: 1790
Feed rate: 0.5-1.5Cubic meters/h
After-sales Service Provided: Free spare parts, Video technical support, Online support
After Warranty Service: Video technical support, Online support, Spare parts
Local Service Location: None
証明: ISO9001,CE
基本情報
証明: ISO9001,CE
Model Number: LWL/Y200
お支払配送条件
Packaging Details: Film wrapped + fumigation-free wooden case
Supply Ability: 10 Set/Sets per Month
製品の説明
Product Description
LWL Series Worm Screw Screen Centrifuge

Performance and Use:
Blovebird horizontal screen scroll centrifuge has the advantages of large production capacity, good solid phase dehydration, low energy consumption and light weight.

Widely used in chemical, food, pharmaceutical and mining industries, and is suitable for the separation of solid-phase suspensions containing coarse crystals and short fibers.

Especially suitable for separating suspension of easy dehydration and high concentration.

MAIN FEATURES

1. Strong pertinence to materials, the crystal size is between 0.05-10mm
2. Continuous operation, Screw unloading, Large production
3. The solid phase has low moisture content, good washing effect and high separation efficiency
4. Dedicated filter screen, material optional, filter screen thickness up to 0.5mm, longer service life
5. Stepless speed regulation of drum speed
6. Simple and reliable lubrication
7. Compact structure, easy operation and maintenance
8. Safety protection: speed detection, oil-free protection, motor overload and overheat protection, spiral zero differential protection.

★LWL series has hundreds of cases in the waste salt treatment industry, including sodium chloride, sodium sulfate, ammonium chloride, ammonium sulfate, ferric chloride, and ferrous chloride. In addition, we have rich experience in plant extraction (tea, ginkgo, iron powder, kudzu root, hemp leaves, etc.), magnesium sulfate, copper sulfate, sodium gluconate, sodium metabisulfite, marine snowmaking, and other industries. Welcome customers from related industries to inquire.

The improvements made by Blovebird in ammonium sulfate, ammonium chloride, ammonium thiocyanate, sodium chloride and other waste liquid salt extraction equipment:
--------------------------------------------------------------------------------------------------------------------------------------------------------
1. The feeding pipe device is improved, the cloth is more uniform, and the equipment operation is more stable;

2. The lubrication system is improved, the lubrication is more adequate and reasonable, and the bearing weight is increased;

3. Improve the bearing sealing system and adopt labyrinth oil seals to prevent mother liquid from entering the lubrication system;

4. The drum spiral is treated with nitriding and wear-resisting, and the service life is longer.

5. The discharging system is improved, and a scraper device is added to prevent the silo from accumulating.

WORKING PRINCIPLE

Under full speed operation: continuous feeding, washing, dewatering, unloading and other technological operations of the suspension.

The suspension enters the spiral cavity from the feed pipe, and enters the drum through the nozzle at the bottom of the screw head near the bottom of the cone.
Under the action of the centrifugal force field, the liquid phase in the slurry is separated by the creen set on the rotating wall When going out, the solid particles are trapped in the drum; at the same time, the solid particles in the drum move from the small end of the drum to the big end of the drum under the action of centrifugal force and the differential speed between the
spiral and the drum.
During the movement, the centrifugal force increases rapidly due to the increase of the rotation diameter. The solid phase changes from the high moisture content solid phase when it initially enters to the low moisture content solid phase when it is discharged from the drum, thus realizing automatic and continuous solid and liquid phase separation.

LWL Series Screw Screen Centrifuge has been successfully used in the following:
Adipic Acid
Potash
Rock Salt
Date Stones
Salt Cake
lon Excgange Resin
Sodium Nitre
Polystyrene Alcohol
Arsenic Triazole
Sodium Chloride
Sodium Perborate
Sodium Thiosulphate
Ah-salt
Anth Racene
Nylon Chips
Copper Sulphate
Naphthenic Sulfonic Acid Ester
Iron Sulphate Hepta Hydrate
Hops From Dichlorc Methare
Ammonium
Thiosulphate
Greaves
Sodium Chlorate
Citric Acid
Tarteric Acid
Aminiacetic Acid
Aspirin
Oxalic Acid
Crystal Soda
Gun Powder
Lactose
Sodium Sulphate
Potash Alum
Regenerated Rubber
Sodium Formate
Polymethacrylate
Tin Sulphate
Ammonium Persulphate
Bisphenol
Sodium Sulphite
Dinitro Methylarlin
Gypsum
Managanese Sulphate
Polysyrene
Potash Solvent Residue
Silver Nitrate
Sodium Gliconate
Sodium Tetraborate
Trisodium
Ammonium Phosphate
Borax
Two Nitro Methylaniline
Extraction from Methanol
Urotropin
Methyl Cellulose
Disodium Phosphate
Potassium Bica Rbonate
Sodium Acetate
Sodium Metaborate
Potassium Lore
Zinc Sulphate
Ammonium Sulphate
Calcium Formiate
Potassium Chloride
Potassium Bichromate
Sodium Phosphate
Monosod lumphasphate
Polyvinyl Chloride
Potassium Pensuphate
Sodium Ca Rbonate
Sodium Nitrate
Potassium Sulphate
Fungal Mycel
--------------------------------------------------------------------------------------------------------------------------------------------------------
Structural Diagram
The drum/screw of the centrifuge can be customized in different angles according to customer requirements.

Material selection:
The material of the part in contact between the centrifuge and the material can be selected from stainless steel (304, 316L, 2205,
etc.), Hastelloy, titanium and other corrosion-resistant materials according to customer requirements.
Configuration selection：
Explosion-proof configuration, gas-liquid separation device at the discharge port, washing device, vibration and main bearing temperature monitoring protection, etc.

The standard cone angle of 20° is suitable for the separation of most materials

The 10° cone angle is suitable for separation processes that require heating and washing effects

0° barrel drum is suitable for the separation of ice crystals and filber derivatives
--------------------------------------------------------------------------------------------------------
LWL-Y Inverted Worm Screw Screen Centrifuge

*Aiming at the shortcomings of traditional worm screw screen centrifuges, Blovebird has developed Y series crush-free clean horizontal screw screen centrifuges after 5 years of research and development.

MAIN FEATURES
1. The parts in contact with materials, such as the drum and screw, can be made of corrosion-resistant stainless steel or titanium alloy.
2. Dedicated filter screen with optional material, the thickness of the filter screen can reach 0.5mm, the mesh density is optional 10-250 mesh, and the service life is longer.
3. The drum speed is variable frequency and steplessly adjustable.
4. Simple and reliable circulating oil lubrication method.
5. Safety protection: speed detection, oil-free protection, motor overload and overheat protection, spiral zero differential protection.

Material selection：
The material of the part in contact between the centrifuge and the material can be selected from stainless steel (304, 316L, 2205,etc.), Hastelloy, titanium and other corrosion-resistant materials according to customer requirements.。

Configuration selection：
Explosion-proof configuration, gas-liquid separation device at the discharge port, washing device, vibration and main bearing temperature monitoring protection, etc.

WORKING PRINCIPLE

The suspension enters the front end of the spiral from the feed pipe, and is initially accelerated by the airflow of the rotating drum into the rotating drum. Under the action of the centrifugal force field, the liquid phase in the slurry is separated by the screen set on the rotating wall, and the solid particles are intercepted. In the drum;
At the same time, the solid particles in the drum move from the small end of the drum to the big end of the drum under the action of centrifugal force and the differential speed between the spiral and the drum. During this movement, due to the diameter of the rotation Increased, the centrifugal force is rapidly increased, and the solid phase changes from the high moisture content solid phase when it initially enters to the low moisture content solid phase when it is discharged from the drum, thus realizing automatic and continuous separation of solid and liquid phases.

The new Y series centrifuge is an improved model based on the LWL series centrifuge. The performance of the machine is more stable, the treatment effect is better, and the service life is longer.

Like the LWL series centrifuge, it is also more specific to materials. Material analysis and corresponding tests should be carried out during the selection to determine its applicability and separation performance.
Customer Cases

Company：Jiangsu Victor Co., Ltd.
Material：Sodium chloride
Capacity：LWL350

Company：Pingxiang Xianwang Industrial Co., Ltd.
Material：Sodium chloride
Capacity：LWL450

Company：Hangzhou Jihua Jiangdong Chemical Co., Ltd.
Material：Ammonium sulfate
Capacity：LWL450

Company：Linhuan Coking Co., Ltd.
Material：Ammonium sulfate
Capacity：LWL450

Company：Heze Yuandong Qiangya Chemical Co., Ltd
Material：Ferric chloride
Capacity：LWL450

Company：Tangshan Siruier Chemical Co., Ltd.
Material：Ferrous chloride
Capacity：LWL450

Company：Linhuan Coking Co., Ltd.
Material：Ammonium sulfate
Capacity：LWL450

Company：Jiangxi Yongtong Technology Co., Ltd.
Material：Sodium sulfate
Capacity：LWL450


Company：Tangshan Zhongrun Coal Chemical Co., Ltd.
Material：Magnesium sulfate
Capacity：LWL350

Company：Zhengzhou Yuda Chemical Co., Ltd.
Material：Copper sulfate
Capacity：LWL450

Company：Kaidi Chemical Co., Ltd.
Material：Sodium gluconate
Capacity：LWL350

Company：Bangze Chemical Co., Ltd.
Material：Sodium pyrosulfite
Capacity：LWL530

Company：Zibo Huayan Chemical Co., Ltd.
Material：Sodium sulfate
Capacity：LWL450

Company：Dongjiang Environmental Co., Ltd.
Material：Sodium chloride
Capacity：LWL350

Company：Nantong Chenlong Chemical Co., Ltd.
Material：Ammonium chloride
Capacity：LWL450


Company：Shandong Aochuang Chemical Co., Ltd.
Material：Magnesium sulfate
Capacity：LWL630
Product Paramenters
Model
Drum Dia
(mm)
Drum Length
(mm)
Speed
(r/min)
Factor
Feeding
(m³/h)
Power
(kw)
200
200
176
4000
1790
0.5-1.5
3
250
250
208
3500
1712
1-5
4
350
350
287
3000
1762
3-15
11
450
450
356
2600
1700
3-18
22
530
530
405
2200
1434
6-20
30
630
630
496
1850
1205
10-30
37
800
800
525
1500
1008
15-40
55
1000
1000
664
1000
560
20-50
90
Packing&Shipping
Our Service

Pre-sales Service

1- Inquiry and consulting support.
2 - OEM service is available.

24 hours online service.

1-Machine operation video
2-Watch our factory online
3-Contact us for more services

After-sales Service

1 - The warranty period is 12 months from the date of arrival of the machine. Offer the free spare parts.
2 - Follow up regularly until the machine works normally.3 - We will remind you of routine maintenance.

Installation, commissioning and training

1- If the customer has demand, we will arrange experienced engineers to go to the local equipment installation, debugging and test
production.
2-Workers can receive training in our factory and in your factory.
Why Choose Us

Zhangjiagang Blovebird Separations Co. Ltd

-Verified Supplier
- Holding 40 Patents
- CE & ISO certificated
- Innovative R&D Team
